1200W 12V 100 AMP High Power AC/DC Switching Power Supply 24V 36V 48V 60V 72V 90V 110V 220V

Basic Info

Model NO.	STS-1200W
Output Type	Single
Warranty	2 Years
Output Power	1000W-1200W
Input Voltage	110-220V
Connection Mode	Series Switching Power Supply
Starting Mode	Self-excited Switching Power Supply
Voltage Regulating Mode	Frequency Modulation Type
Power Supplying System	Level 1 Power Distribution Equipment
Energy Transmission	Two-way Transmission
Modulation System	PFAW
Certification	CE
Brand	DSS
Specification	238*127*61mm
Trademark	CHSTSI
Origin	Zhejiang Wenzhou

Product Description

Detailed Photos Our company is a high-tech company specialized in designing. R&D. Production and sale,The products"Switching Power Supply"are with the characteristics of the low price,High efficiency, high reliability, long lifetime and so on.Our products are widely usedIn industrial automation field, indoor and outdoor LED lighting,LED lighting projects, Communication, instrumentation, etc.Our Switching Power Supply isthe ideal upgraded Product to replace traditional controlling transformer.

Item		Technical specifications
Output	Rated power	1000W-1200W
	DC voltage	0-12V	0-24V	0-48V	0-72V	0-90V
	Ripple and noise	<200mv	<200mv	<290mv	<290mv	<290mv
	Voltage accuracy	±1%
	Load adjustment ratio	0.3%	0.3%	0.3%	0.3%	0.3%
	Linear adjustment rate	0.50%
Input	Voltage range	108-264VAC 47Hz-63Hz;245VDC-370VDC
	Efficiency (Typical)	>80%	>80%	>80%	>80%	>80%
	Operating current	220V AC;18A
	Pulse current	60A 230V AC
	Start-up, Rise and hold times	2000ms,50ms,20ms;230VAC
Protection	Overload protection	105%-135% Type, Constant current output + Cut off output and reset when V0 drops below undervoltage point, Power on again.
	Over-temperature protection	RTH3, The fan runs continuously, And output is shut off when the temperature ≥90°C.
Environment	Operating temperature, Humidity	10ºC~+50Degree centigrade:20%~90RH
	Storage temperature, Humidity	20ºC~+85Degree centigrade:10%~90RH
Safety standards	Withstand voltage	Input-Output: 15KVACInput-Enclosure: 15KVACOutput-Enclosure: 0.5KVACDuration: 1 minute
	Leakage current	1.5VAC<6mAInput-output1.5VAC <6mA
	Leakage current	220VAC<1.5mAInput-output220VAC<1.5mA
	Isolation resistance	500VDC/100MQ
Others	Product Dimension	238*127*61MM
	Product Weight	1.45KGS
	Package Size	41*28*29CM ( 10 pcs/Carton)
	Net weight	14.5KGS
	Gross Weight	15.5KGS

FAQ:1
Q:Are you a manufacturer?
A: Yes,we are a professional and origin switching power supply manufacturer. 2
Q: What warranty do you offer?
A: Each product with 2 year warranty,expect the human damage and force majeure factor .Beyond the guarantee period machine ,we will provide maintenance service and technical support. 3
Q: What about minimum order quantity?
A: We have no limit for big quantity, but you'd better buy only one carton at least. 4
Q: Can you do OEM/ODM?
A: Yes, we are factory and we can customize as your requirements. 5
Q:What kind of inspection you can provide ?
A: Each switching power supply will ageing test 24 hours ,to guarantee all goods are in the perfect condition before shipment .we also accept the inspection by the third part you appointed.
